Spec

• Cooling/Circulation System: Air Cooling/Open System Directional Circulation
• Temperature adjustment range: - 10 ~ 80 degrees C
• Temperature control accuracy: from +/- 0.2 degrees C
• Cooling capacity (at liquid temperature): 10 degrees C/200 W (about 170 kcal/h), -10 degrees C/120 W (about 100 kcal/h)
• External circulation capacity (50/60 Hz): Maximum flow rate 7/7. 5 L/min, Maximum head: 4.5 m/6.0 m (Discharge pressure: 0.045 MPa/0.06 MPa)
• Temperature control: P.I.D control, SSR output
• Temperature sensor: Platinum temperature resistor Pt 100 ohm
• Temperature setting/display: Sheet key input/digital display, minimum setting digit 0.1 degrees C
• Timer function: Auto start, Auto stop 2-step program
• Safety features: Self-diagnostic function (Upper and lower temperature, power outage, refrigerator, sensor flow, watchdog, air-in, freezing, heater cleaning time), leakage/overcurrent breaker, refrigerator overload relay, indep***ent overrise detector (120 degrees Celsius setting)
• External input/output: external temperature sensor terminal, alarm output terminal: non-voltage contact (b contact) AC 250 V/DC 30 V Max. 2 A, recorder output terminal: 1 ~ 4 VDC (25 mV/deg. C)
• Heater: 550 W (SUS 316 L)
• Refrigerator/Refrigerant: Air-cooled Output: 300 W/R 134 a
• Circulation pump: Self-priming pump 60/80 W (self-priming 2 m)
• Cooling Coil: SUS 304
• Circulating nozzle: both discharge port and return port 10.5 mm outer diameter hose port
• Water Tank Capacity/Material: About 1 L/SUS 304
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 324 x 397 (437) x 482 (502)/* Dimensions in () include projections.
• Weight: approximately 35 kg
• Power input/voltage: 10.5 A, 1.05 kVA/100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, clean water, rated power supply voltage, 50 Hz and no load.
• *Cooling capacity is the capacity of the device in the cooling tank. It differs from the ability of conventional methods with external water tanks.
• *Cooling capacity is +/- 10% of display capacity.
• *Comes with 1m x 2 cooling hoses.
• *Pure water can not be ***d.
• Code: 204880
