63-1269-46 Hot Plate (With Temperature Controller) PA2012-WPFC-PCC20A
Product Description
Product Model: 63-1269-46Product Brand: MSA FACTORY Fea […]
Contact Us
Product Details
Product Model: 63-1269-46
Product Brand: MSA FACTORY
Features
- Hot Chuck with Porous Ceramic Waterproof Function
- Maximum temperature 200°C High-precision type.
- The dedicated temperature controller has a multi-point PID function (automatic PID parameter switching in each temperature range), and high-precision control from room temperature to maximum temperature can be ***d from the day of installation. (factory-set PID)
Spec
- Maximum temperature: 200 deg.
- Plate size: 120 mm
- power supply Voltage : AC100V
- Electric capacity: 1200 W
- Hot plate cable: 1 m
- power supply Cable: Receptacle Cable with GND 2 m
- Sensor Type: K class thermocouple
- Waterproof Type
- Temperature Distribution ± 1.5%
