Spec

• Output Power: 40/48/6W
• Input voltage range: AC 85 ~ 265 or DC 120 ~ 330
• Output Voltage: 5/+ 12/-12 V
• Output Current: 8/4/0.5 A
• Efficiency (typ): 0.72
• Operating temperature range: -10 to + 65 (-10 to + 50: 100%, + 65: 50%)
• Dimensions: 42 x 92 x 188 (mm)
• Notes: With cover, harmonica terminal
• CE marking (Low Voltage Directive Compliant) CE marking by EN 60950 certification
• Machine command response (VDE0160 certified)
• Wide input voltage range: 85 ~ 265 VAC continuous input
• Harmonic current suppression (according to EN 61000 -3 -2)
• EMI (EN 55011 B, EN 55022 B, VCCI-B, FCC-B Compliant)
• EMS (Complies with EN 61000 -4 -2, -3, -4, -5, -6)
• RoHS compliant
