1-3340-02 ［Discontinued］Sound Level Meter 6238
model:
1-3340-02
category:
toner
Product Description
Product Model: 1-3340-02 Features Just replacing suppli […]
Contact Us
Product Details
Product Model: 1-3340-02
Features
- Just replacing supplied analysis card, RSR（Real Sound Recording） and FFT analysis are available.
Spec
- Model number: 6238
- Precision sound level meter
- Item to be measured: Noise level LA, sound pressure level Lc/Lp, equivalent noise level LAep, hour rate noise level the large value Lmax/the small value/L05/L10/L50/L90/L95
- Measurement range: A characteristics/28 - 130dB, C characteristics/37 - 130dB, Z (FLAT) characteristics/39 - 130dB, C/Z (FLAT) characteristics peak sound pressure level/55 - 135/60 - 135dB
- Memory: Internal memory or SD card
- Interface: USB1.1
- Supported OS: Windows(R)95/NT (4.0 or more)/XP (SP2 or greater) /VistaTM/7/8.1
- Power supply: AA alkali dry cell x 4 volumes (test included) or AC adapter (optional)
- Size: 86 x 46 x 285mm
- Weight: Approximately 450g (including cell)
- JIS C1509-1-^-2005 standards class1
- Set content: Body, SD card, Windbreak screen, Driver for adjustment, Hand strap, Storage case, 1/1 & 1/3 octave effective hour minutes analysis card
