63-6581-25 LED Reflector Bulb, Midget Groove, Red, Single Chip, 6mm dia., 24V ac/dc 203-593
Product Description
Product Model: 63-6581-25Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-6581-25
Product Brand: RS PRO
Features
- Midget Grooved ac/dc LED Indicator, T1 3/4
- Brought to you by the trusted RS Pro brand, this single-chip LED indicator features a recessed lamp and a bright-enhancing reflector. LED lights provide a low-power, long-life alternative to incandescent filament bulbs. Compact and robust, this LED indicator has a midget grooved shape for quick and easy installation.
- Features and benefits: Can be identified by the color of the half-wave rectifier body The anode is a base-contact reverse polarity protective diode
Spec
- Voltage Rating:24V ac/dc
- Light Output Colour:Red
- Intensity:1750mcd
- Lamp Base:Midget Groove
- Chip Type:Single Chip
- Diameter:6mm
- Length:16mm
- Viewing Angle:30 °
- Peak Wavelength:630nm
- Current Rating:14mA
- Life Hours:100000h
- CODE No.:203-593
