Spec

• Temperature Setting Range: Room Temperature +5~80°C
• Tank Capacity: 27 L
• Temperature Distribution Accuracy: Within ±0.3°C (This is the value at the set water temperature of 40°C and room temperature of 20°C.)
• Pump Capacity (50/60Hz): 11/12L/min
• Temperature Control System: Heater PID Control (SSR Output)
• Safety functions: Self-diagnosis function, earth leakage breaker, abnormal heating prevention device, float type dry heating prevention, external output, timer function, program function
• Power: 100 VAC, 50/60Hz
• Maximum operating current: 14 A
• Power Cord: 3P Plug + Adapter
• Material: Body/Steel, Water Tank/SUS304+ Glass
• Weight: 22 kg
• Accessories: Shelf Board x 1, Shelf Board Receiver x 4, Stand x 1, Clamp x 1, Clamp Holder x 1
• External Dimensions: 505 x 360 x 370 mm
• Inner Dimensions: 300 x 300 x 300 mm
• Effective Inner Dimension: 225 mm
• *The effective inner dimension indicates the maximum depth when the shelf board is ***d.
• *The unit itself has no cooling function. By using separately sold cooling coils (1-5457-11) and cooling water circulation device (1-5469-41), etc., it is possible to control temperature below room temperature.
• This product is compatible with the validation service (IQ/OQ). Please contact us.
• *The validation service is a service where installation qualification (IQ) and operation qualification (OQ) are performed at the customer's site and an inspection report is submitted.
