63-4983-51 8 Way Preci-Dip Straight Through Hole 1.27mm SIL Socket, Solder, 1A 100 V ac, 150 V dc 851-87-008-10-001101
Product Description
Product Model: 63-4983-51Product Brand: Preci-Dip Featu […]
Contact Us
Product Details
Product Model: 63-4983-51
Product Brand: Preci-Dip
Features
- UL 94V-0. 1.27 mm IC Socket Connectors. These Swiss Preci-dip IC Ultraminiature PCB Socket Connector headers are solder tail Through Hole or SMD perp***icular Gull-Wing mount. Mating pin Ø 0.38 mm → 0,5 mm The Through Hole headers have a Tail length of 2.3 mm for SIL and 2.4 mm for DIL The SMD mounting headers are perp***icular Gull-Wing type Sockets have Tin plated Brass sleeves with Flash Gold plated Beryllium Copper (4 finger) contact clips
Spec
- Quantity：1bag(5pieces)
- Number of Contacts : 8
- Contact Material : Beryllium Copper, Brass
- Contact Plating : Gold, Tin
- Orientation : Straight
- Termination Method : Solder
- Mounting Type : Through Hole
- Housing Material : Glass Fibre Reinforced PCT
- Current Rating : 1A
- Voltage Rating : 100 V ac, 150 V dc
- Dimensions : 10.57 x 2.2 x 4.1mm
- Depth : 4.1mm
- Length : 10.57mm
- Maximum Operating Temperature : +125°C
- Minimum Operating Temperature : -55°C
- Width : 2.2mm
- CODE No.:702-3066
