63-4976-12 TRACOPOWER THI 2W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 5.5 V dc, Voltage out 5V dc THI 0511
Electronic/Electrical Parts and Controll Equipments

63-4976-12 TRACOPOWER THI 2W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 5.5 V dc, Voltage out 5V dc THI 0511

model: 63-4976-12
brand: TRACOPOWER

Product Description

Product Model: 63-4976-12Product Brand: TRACOPOWER Feat […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4976-12
Product Brand: TRACOPOWER

Features

  • EN 60950, IEC 60950, IEC 60601, EN 60601-1. Derates 3% per °C above 60°C MTBF to MIL-HDBK-217 E (25°C). 3. Traco 2W DIP Single/Dual Output Medical Approved Regulated Isolated DC-DC Converter - THI Series. Regulated outputs High isolation test voltage 6kV peak Supplementary insulation for working voltage up to 250Vac Short circuit protection UL 94V-0 package material 24-pin DIP plastic package (dimensions 32x20x10mm)

Spec

  • Quantity:1piece
  • Output Voltage : 5V dc
  • Input Voltage Range : 4.5 → 5.5 V dc
  • Input Voltage Nominal : 5 V dc
  • Isolation Voltage : 2.5kV
  • Power Rating : 2W
  • Output Current : 400mA
  • Mounting Type : Through Hole
  • Number of Outputs : 1
  • Package : DIP 24, PDIP
  • Load Regulation : ±1%
  • Maximum Temperature : +75°C
  • Depth : 10mm
  • CODE No.:699-2722
