63-7713-17 Sensata / Crydom 6 A Solid State Relay, DC, DIN Rail, 100 V dc Maximum Load DRA1-CMXE100D6
model:
63-7713-17
brand:
Sensata / Crydom
Product Description
Product Model: 63-7713-17Product Brand: Sensata / Crydo […]
Contact Us
Product Details
Product Model: 63-7713-17
Product Brand: Sensata / Crydom
Features
- Regardless of SSR rating, the DIN-rail socket limits the continuous current rating of the modular assembly to 8A. DIN Rail Mount - DRA1-CMX Series. 10mm single channel DIN rail mount SSR assembly DC ratings up to 200 Vdc and 8 A 3-10 and 20-28Vdc control SPST-NO function Cage style screw terminals for easy connection Fits standard 35mm DIN rail Includes LED Status indicator
Spec
- Quantity:1piece
- Minimum Load Current : 0 A
- Maximum Load Current : 6 A
- Series : DRA1 CMX
- Minimum Load Voltage : 1 V dc
- Maximum Load Voltage : 100 V dc
- Minimum Control Voltage : 20 V dc
- Maximum Control Voltage : 28 V dc
- Switching Type : DC
- Maximum Turn On Time : 1 ms
- Dimensions : 89.6 x 10 x 61mm
- Height : 61mm
- CODE No.:701-8483
