63-4774-77 McLennan Servo Supplies Bipolar Permanent Magnet Stepper Motor 18°, 3.9mNm, 5 V, 125 mA, 4 Wires 15M020D-1B
model:
63-4774-77
brand:
McLennan Servo Supplies
Product Description
Product Model: 63-4774-77Product Brand: McLennan Servo […]
Contact Us
Product Details
Product Model: 63-4774-77
Product Brand: McLennan Servo Supplies
Features
- Series M, Stepper Motor. A range of McLennan permanent magnet stepper motors that ***s the simplest of designs and techniques to create an effective solution for many applications, where reasonable accuracy and moderate torque are required. Generally large frame size motors deliver more torque. The M series of stepper motors are best suited where large volumes are likely.
Spec
- Quantity：1piece
- Step Angle : 18°
- Holding Torque : 3.9mNm
- Number Of Wires : 4
- Voltage Rating : 5 V
- Stepper Motor Type : Permanent Magnet
- Shaft Diameter : 1.5mm
- Current Rating : 125 mA
- Winding Arrangement : Bipolar
- Shaft Length : 8.5mm
- Depth : 15.11mm
- Number of Pole Pairs : 2
- Resistance Per Phase : 40Ω
- CODE No.:368-0261
