6-9183-31-24 ［Discontinued］Cloud-compatible USB connection temperature data logger with JCSS calibration certificate TR71A
Product Description
Product Model: 6-9183-31-24Product Brand: T&D Corpo […]
Contact Us
Product Details
Product Model: 6-9183-31-24
Product Brand: T&D Corporation
Features
- With JCSS Certified Symbol Calibration Certificate (Including Results)
- *I have attached the calibration certificate which was subjected to JCSS calibration test at the time of shipment.
- *Calibration certificates with JCSS certified symbols can meet the requirements of standards such as ISO/IEC 17025, the international standard for testing laboratories and calibration organizations, ISO9000S, the international standard for quality systems, and IATF 16949 (ISO/TS 16949), the quality system for the automotive industry.
- A data logger connected to the cloud that measures and records temperature. By using "Ondotori Web Storage," a free cloud service, it is possible to check the temperature "from anywhere at any time" with a smartphone or PC.
Spec
- Measurement target: Temperature 2ch
- Measurement range: -40~110°C
- Primary accuracy: mean ±0.3°C (at – 20~80°C)
- Indications: Measurements, Battery Life Warning, etc.
- Data capacity: 30,000x2ch
- Recording interval: 15 ways: 1 second to 60 minutes
- Record Mode: Endless/One Time
- Communication: Wireless LAN, USB communication
- Bluetooth:4.2(Bluetooth Low Energy)
- How to check alerts: Email, Browser
- Power: 2 AA alkaline, AC adapter, USB bus power
- Operating environment: Temperature: 10~60°C Humidity: 90%RH or less No condensation
- Size: H58 x W78 x D26mm
- Waterproof: None
- Battery Life: Approximately 10 days to 15 months
- Accessories: Temperature sensor (TR-0106) x2, AA alkaline battery (LR6), registration code label, instruction manual (with warranty) set
- With VFC mode
- The calibration point is 1 point at 23°C. If you would like other points, please contact us separately.
