Spec

• Model number: TR-K
• Settings range: 0 - 999℃*
• Minimum display unit: 1℃
• Sensor sheath material: Stainless steel (SUS316)
• Sensor size: φ3.2 x 200mm
• Lead wire length: 2m
• Number of channels: 1
• Temperature control accuracy: +/- (0.3% FS + 1 digit)
• Temperature control: ON/OFF control (relay system)
• Attached sensor: K thermocouple x 1
• Main unit size: 135 x 145 x 95mm
• Power supply: 100VAC 50/60Hz
• Power cord length: 2m x 1
• Contact capacity: MAX15A
• *Measurement range using the included K class thermocouple sensor is 0 - 750℃.
• *Install as the temperature of sleeve portion to be 100℃ or less.
