Spec

• Display: 3999 count LCD
• Measurement items: DC voltage, AC voltage, DC current, AC current, resistance, frequency, continuity check, duty ratio, capacitor, diode check
• Measurement Range (* Maximum Accuracy) DC Voltage: 400 m/4/40/400/600V *± (0.8%rdg+2dgts)
• Measurement Range (* Maximum Accuracy) AC Voltage: 4/40/400/600V *± (1.2%rdg+3dgts)
• Measurement Range (* Maximum Accuracy) DC Current: 400μ/4000μ/40 m/400 mA *± (1.0%rdg+3dgts)
• Measurement Range (* Maximum Accuracy) AC Current: 400μ/4000μ/40 m/400 mA *± (1.5%rdg+3dgts)
• Measurement Range (* Maximum Accuracy) Resistance: 400/4k/40k/400k/4M/40 MΩ *± (1.0%rdg+2dgts)
• Measurement Range (* Maximum Accuracy) Frequency: 5/50/500/5k/50k/500k *± (0.5%rdg+3dgts)
• Duty ratio: 0.1~99.9%
• Capacitor (* highest accuracy): 50n/500n/5μ/50μ/100 μF *± (4%rdg+3dgts)
• Diode Check: Measure the forward voltage of the diode
• Conductivity check: Alarm (buzzer) sound sounds at approximately 10 Ω or less.
• Maximum input voltage: DCV 600VDC, ACV 600Vrms
• Maximum input current: 400 mA (mA range), 4000 μA (μA range)
• Input Impedance: Approx. 10 MΩ or More (DC/AC Voltage Range)
• Sampling rate: 3 times/second
• Power supply/battery life: CR2032 type lithium battery 1/approx. 60 hours
• External dimensions/mass: 109.8 (W) x 10.8 (H) x 58.2 (D) mm/approx. 76 g (including battery)
• Accessories: Owner's Manual, Storage Case, Battery (Built-in)
• *Since the circuit protection element ***s a PPTC element instead of a f***, the circuit protection element cannot be replaced.
