Spec

• Measurement system: Both electromagnetic and eddy current type (with automatic discrimination function)
• Measurement object: Non-magnetic film on magnetic metal and insulating film on non-magnetic metal
• Measurement range: 0~2000 μm
• Measurement accuracy: < 50 μm ±1 μm, 50 μm to < 1000 μm ±2%1000 μm to < 2000 μm ±3%
• Applicable standards: Electromagnetic induction type: JIS K5600-1-7, JIS H8501, JIS H0401/ISO 2808, ISO 2064, ISO 1460, ISO 2178, ISO 19840/BS 3900-C5/ASTM B 499, ASTM D 7091-5, ASTM E 376 Eddy current type: JIS K5600-1-7, JIS H8680-2, JIS H8501/ISO 2808, ISO 2360, ISO 2064, ISO 19840/BS 3900-C5/ASTM D 7091-5, ASTM E 376
• Resolution: < 100 μm 0.1 μm100 μm or more 1 μm
• Display method: Digital (LCD with backlight, minimum display digit 0.1 μm)
• Data memory: approx. 1000 points
• Application Memory: Stores a total of 16 calibration curves of 8 types each of electromagnetic and eddy current types.
• Power Supply: Battery 1.5 V (AAA Alkaline) x 2
• Power consumption: 40 mW (when the backlight is not on)
• Operating temperature range: 0~40°C
• Function: Calibration curve memory (application memory), measurement data memory, data deletion, data output, lot classification, automatic power ON/OFF, function, clock function, upper/lower limit setting, statistical calculation, backlight function, unit setting, etc. 15 functions
• External output: Can be output to a personal computer (USB) or printer (RS-232 C)
• Dimensions/Mass: 82 (W) x 99.5 (D) x 32 (H) mm, approx. 160 g
• Accessories: 0 Plate Holder (Iron and aluminum fabrics), Standard Plate (Approximate value for 50 μm, 100 μm, 1000 μm, 1 sheet each), Carrying Pouch, Battery 1.5 V (AAA Alkaline) x 2, Wrist Strap
• Options: Standard Plate (thickness not included), Measuring Stand LW-990, Printer (VZ-330 or VZ-380), Printer Cable, USB Cable, Transparent Cover, Data Management Software: Data Logger LDL-01
