Spec

• Convection system: Forced convection system (with airflow control)
• Temperature adjustment range: 4 ~ 60 degrees C
• Temperature control accuracy: +/- 0.2 degrees C or lower (all temperature ranges)
• Temperature distribution accuracy (at 37 degrees C setting)/space temperature deviation 1.2 degrees C or less, temperature gradient 1.5 degrees C or less, (total temperature range)/space temperature deviation 2.0 degrees C or less, temperature gradient 3.0 degrees C or less
• Safety features: Leakage/overcurrent breaker, bimetal for heater, f***, temperature controller self-diagnostic function (Temperature Upper and Lower Limits, Temperature Uncontrollable, Power Failure, Heater Disconnection, Sensor Disconnection, Watchdock)
• Program features: Auto Start, Auto Stop, Auto Start Stop
• Timer function: 1-step, 2-step repetition
• Accessory functions: Internal fan airflow control function (1: weak to 4: strong), temperature correction function
• Defrosting features: Auto defrost (every 3 hours), Manual defrost (auto finish)
• Heating method: Stainless sheath heater 150 W
• Cooling system: Peltier module (air-cooled)
• Temperature sensor: Platinum temperature resistor Pt 100 ohm
• Interior dimensions (width x depth x height): 280 x 250 x 250 mm
• Internal volume (L): about 17.5
• Shelf Board Load Capacity, Material: Equal Distribution Max. 3 kg/Sheet, SUS 304
• Shelf Plates Included: 1
• Shelf Pitch/Number of Racks: 26 mm/6 Racks
• Interior and inner doors: SUS 304, made of tempered glass
• Stacked: Up to 3
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (width x depth x height): 585 x 390 x 410 mm
• Weight (kg): approximately 25
• Power input/voltage: 5 A 500 VA/100 V AC 　50/60Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, 50 Hz, airflow (4: strong) and no load.
• *Performance notation for temperature distribution conforms to JIS C 60068 -3 -5 JTM K 07 -2007 (Performance test method and performance display method of temperature test tank, Japan Testing Machine Industry Association).
• *Minimum/maximum attainable temperature, temperature control accuracy and temperature distribution accuracy vary dep***ing on operating conditions such as room temperature, heat load conditions and power supply voltage.
• Code: 266810
