Electronic/Electrical Parts and Controll Equipments
63-7689-75 Vishay LPS300 Series Screw Termination Thick Film Panel Mount Resistor, 820mΩ ±5% 300W LPS0300HR820JB
Product Description
Product Model: 63-7689-75Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-7689-75
Product Brand: Vishay
Features
- LPS300 Series 300 W Thick Film Power Resistor. LPS300 series 300 W thick film power resistors for mounting onto a heatsink. These LPS300 power resistors have a rating of 300 W at 85°C bottom case temperature, a low thermal radiation of the case and offer a wide resistance range from 0.3 to 900 kΩ.
Spec
- Quantity:1box(15pieces)
- Resistance : 820mΩ
- Power Rating : 300W
- Series : LPS300
- Tolerance : ±5%
- Technology : Thick Film
- Termination Style : Screw
- Minimum Operating Temperature : -55°C
- Maximum Operating Temperature : +120°C
- Maximum Temperature Coefficient : ±500ppm/°C
- Temperature Coefficient : ±500ppm/°C
- CODE No.:167-8603
