61-8513-44 ［Discontinued］Full-Color Portable 2 Phenomena Oscilloscope + 4000 Count DMM MT-770
Product Description
Product Model: 61-8513-44Product Brand: MOTHERTOOL CO., […]
Contact Us
Product Details
Product Model: 61-8513-44
Product Brand: MOTHERTOOL CO., LTD.
Features
- 2 Phenomenon Color Oscilloscope
- 4000 count true effective value DMM function
- USB communication function installed
Spec
- LCD specification: 3.8 inches, Color LCD
- Number of input channels: 2 channels
- Frequency band: 20MHz
- Sampling: Maximum 100MS/S
- Voltage axis range: 5mV/div - 5V/div
- Time axis range: 5ns/div - 5s/div
- Input impedance: 1MΩ
- Trigger: Edge (normal, Single shot, Auto), Video
- Maximum record length: 6000 points each
- Digital tester function
- DC voltage: 400mV - 400V
- AC voltage: 4V - 400V
- DC current: 40mA - 20A
- AC current: 40mA - 20A
- Capacitance: 51.2nF - 100μF
- Resistance: 400Ω - 40MΩ
- Usage power supply: AC adapter
