Features

• Description
• The High Quality Camera Module is a camera sensor designed to accept CS-mount lenses and, with the supplied adapter, C-mount lenses for *** with the Raspberry Pi single board computer line. It offers higher resolution(12 megapixels, compared to eight megapixels), and sensitivity(approximately 50% greater area per pixel for improved low-light performance)than the existing Camera Module v2. The 12.3 megapixel Sony IMX477 sensor features a 7.9mm diagonal image size and back-illuminated sensor architecture with adjustable back focus. Additionally, this module features an included tripod thread just adjacent to the ribbon cable connector.
• The CGL 6mm CS-mount and 16 mm C-mount lenses(in the related products section below)are examples of third-party products that are compatible with the High Quality Camera; see step-by-step instructions for fitting these CS-mount and C-mount lenses in the documents tab. Additional adapters can also be found for *** with professional DSLR lenses.
• Note:A lens is required for this camera module and one is not included.
• Features
• Sony IMX477R stacked, back-illuminated sensor, 12.3 megapixels, 7.9mm sensor diagonal, 1.55μm×1.55μm pixel size
• Ouput:RAW12/10/8, COMP8
• Back focus:Adjustable(12.5mm - 22.4mm)
• Lens standards:C-mount, CS-mount(C-CS adapter included)
• IR cut filter:Integrated
• Ribbon cable length:200mm
• Tripod mount:1/4in. - 20
