Electronic/Electrical Parts and Controll Equipments
63-4631-98 RS PRO, 5V dc Coil Non-Latching Relay SPDT, 2A Switching Current PCB Mount Single Pole 476-757
Product Description
Product Model: 63-4631-98Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-4631-98
Product Brand: RS PRO
Features
- UL (File No. E133481), CQC (File No. CQC 02001001948)
- Subminiature signal relay
- High coil sensitivity: 150 mW 2 A switching capacity (maximum) Contact rating: 0.5 A (125 Vac), 1 A (30 Vdc) Wash-resistant
Spec
- Coil Voltage:5V dc
- Coil Power:150mW
- Coil Resistance:167 Ω
- Isolation Coil To Contact:1kV ac
- Contact Configuration:SPDT
- Mounting Type:PCB Mount
- Switching Current:2A
- Terminal Type:Through Hole
- Number of Poles:1
- Maximum Switching Voltage AC:125V ac
- Maximum Switching Voltage DC:60V dc
- Height:10mm
- CODE No.:476-757
