Spec

• Size (mm): 590 x 450 x 255
• Weight (kg): 19
• Double beam
• Wavelength range: 190 ~ 1100 nm
• Spectral bandwidth: 1 nm
• Wavelength accuracy: +/- 0.3 nm
• Wavelength reproducibility: 0.2 nm
• Measurement system: Double beam (1200 lines/mm)
• Measuring range: transmittance/0 ~ 200% T, absorbance/-0.3 to + 3 A
• Accuracy of measurement: Transmittance/+/- 0.3% T
• Stray: 0.04% T @ 220 nm, 360 nm
• Scan speed: up to 3000 nm/min
• Stability: 0.0003 A/h @ 500 nm
• Cell holder: 2 sets for 10 mm square cell optical path length
• Light source: tungsten lamp, deuterium lamp
• Interface: USB, parallel port
• Operating System: Windows (R) 7/8/8.1/10 (32/64 bit)
• Power supply: 100 VAC 50/60 Hz
• Accessories: USB cable, 4 glass square cells, 2 quartz square cells, USB memory, software (CD)
• Inspection contents App***ix: Inspection inspection documents
• Confirmation of baseline, wavelength accuracy and transmittance of 50%
• App***ix: Inspection Certificate documents
• *Products with Inspection Certificate are Azwan's original service that includes inspection of control and electric engine personnel and issuance of inspection documents at the time of shipment.
