4-5456-01 thermographic camera Pivot-IR
Product Description
Product Model: 4-5456-01Product Brand: ICI Spec Resolut […]
Contact Us
Product Details
Product Model: 4-5456-01
Product Brand: ICI
Spec
- Resolution: 256 x 192
- Resolution: 0.05 °C
- Measurement temperature range: -20 °C to + 550 °C
- Accuracy: +/- 2% or +/- 2 degrees C, whichever is greater.
- Minimum display unit: 0.1 °C
- Measurement wavelength: 8 ~ 14 μm
- Viewing angle: 56 ° x 42 °
- Zoom: Yes (3 Levels/x 1, x 2, x 4)
- Lens module range of motion: 0 °, 30 °, 60 °, 90 °
- Screen size: 1,920 x 1,080/color touch panel
- Color palette: 7 colors
- Image Display Modes: 4 (Infrared, Merge, Small Window, Visible)
- Save format: JPG (with audio annotation)
- Internal memory: 16GB
- Interface: USB Type-C
- PC connection: Yes (export image data)
- Power: 5V Rechargeable Lithium Ion Battery (Built-in)
- Standard time for continuous operation/charging: 6 hours/3 hours
- Auto Power Off function
- Dustproof waterproof protection rating: IP54
- Size: 142 x 76 x 19 mm
- Weight: 210 g
- Tripod connection: Yes (1/4-20UNC)
- Quantity: 1 unit
- Accessory: USB cable (type A to typeC)
- Dedicated Case/Strap
- Quality/Manufacturer's Warranty (English ver.)
- Temperature Test Report/Results (English ver.)
