1-3889-31 Stabilized DC Power Supply (Wide Range) 71 x 351 x 124 mm 360 W PSW-360L80A
Product Description
Product Model: 1-3889-31Product Brand: TEXIO TECHNOLOGY […]
Contact Us
Product Details
Product Model: 1-3889-31
Product Brand: TEXIO TECHNOLOGY
Features
- This is a switching-type DC stabilized power supply that enables a wide range of voltage and current output within the maximum rated power.
- A total of 15 models are available with 3 types of output capacity (360 W/720 W/1080 W) and 5 types of maximum voltage (30 V/80 V/160 V/250 V/800 V) for a wide range of applications.
- Equipped with USB and LAN ports as standard, it can also be built into a rack, so it can be ***d as a system power supply.
- It also complies with CE Marking and the European RoHS Directive (as of May 2024).
- Functions such as logging, constant power control, tUVP, and FAN stop are standard.
Spec
- Size (mm): 71 x 351 x 124
- Output voltage: 360 W
- Output current: 0~13.5 A
- Rated power: 0~80 V
- Display and Output Range: Setting Resolution: Voltage 10 mV/Current 10 mA/Power 10 W(A wide range of voltage and current can be set within the rated power range.)
- Functions: Test mode, output slew rate setting, variable internal resistance, CC/CV priority mode, bleeder circuit ON/OFF
- Master-slave operation: parallel connection/3 units of the same model, series connection (Excluding 250 V and 800 V models)/2 units of the same model
- Interfaces: External analog control, LAN (Ethernet) port, USB host/device port, GP-IB (optional)/GUG-001 (GP-IB-USB converter), RS-232C (optional)/GUR-001B
- Power Supply Voltage: 100~240 VAC/50~60 Hz Worldwide Compatible (However, the standard included power cord is only for 100 VAC)
