Spec

• Model number: PSW -1080 L 80
• Size (mm): 214 x 350 x 124
• Output (Current/Voltage) rating Power: 0 to 80 V/0 to 40.5 A/1080W
• Display and Output Range: Setting Resolution: Voltage 10 mV/Current 10 mA/Power 10 W (A wide range of voltage and current settings is available within the rating power range.)
• Various functions: test mode, output slew rate setting, variable internal resistance, CC/CV priority mode, bleeder circuit ON/OFF
• Master-slave operation: parallel connection/three identical models, serial connection (Excluding 250 V and 800 V models)/two identical models
• Interface: external analog control, LAN (Ethernet) port, USB host/device port, GP-IB (Options)/GUG-001 (GP-IB-USB converter)
• power supply Voltage : AC100 to 240 V/50 to 60Hz Worldwide (However, the standard attached power cord is for AC100V only.)
• Accessories: Calibration certificates
• *Products with calibration certificate is a service where equipment is calibrated and calibration certificate is issued at the time of shipment.
