Spec

• All-in-One Electromyometer (EMG) sensor board
• The MyoWare Muscle Sensor is an Arduino-based all-in-one electromyography (EMG) sensor from Advancer Technologies. Measuring muscle activity by detecting electrical potentials is called electromyography (EMG) and is ***d in medical research. This sensor can measure the electrical activity of muscles. Outputs 0 to Vs volts dep***ing on the activity of the selected muscle. Vs is the power supply voltage. Unlike previous versions, you can connect directly to 3.3 V through the 5 V development board. Electrodes (biomedical sensor pads) can now snap directly to the MyoWare muscle sensor and can be mounted without cables.
• Get Started with the MyoWare Muscle Sensor Guide
• Specifications
• Single power operation: +2.9 V to +5.7 V, polarity reversal protection
• Output modes: EMG envelope, Raw EMG
• Shielded expandable
• LED indicator x 2(For power supply and myoelectric detection)
• On/Off switch
• Designed exclusively for microcontrollers
• Gain adjustable
• Size: 21 mm x 51.5 mm
