Spec

• Introductory kit using SparkFun's Arduino-compatible microcomputer board Pro Mini
• Get started building and programming with Arduino with a starter kit of 3.3 V/8 MHz Pro Mini and its peripherals. Pro Mini has no built-in connectors, so you can solder connectors and wires in the orientation you prefer.
• The voltage regulator on the board can input up to 12VDC, but when applying unadjusted voltage, connect it to the RAW pin, not the VCC. FTDI board is included for USB connection.
• In addition to the Pro Mini and FTDI board, the kit includes 40 male headers, 6 right angle male headers (ideal for FTDI connections), 2 2 pin female headers for offsetting the A6/A7 and SDA/SCL pins, a mini breadboard, jumper wire, and more.
• [Set Contents]
• Arduino Pro Mini 328(3.3V/8MHz)
• FTDI Basic Breakout (3.3 V)
• Breadboard (Mini-modular, White)
• USB Mini-B cable (150 mm)
• Pin Header (Straight, 40 pin)
• Pin Header (Light Angle, 6 Pin)
• Female Pin Header (2 Pin) x 2
• Jumper Wire (Male - Male, 30 Pack)
• LED(Red, 3mm), LED(Green, 3mm)
• Resistance (330 ohms, 1/6 watts)×2
• Arduino Pro Mini 328 CPU: ATmega328(8 MHz, tolerance 0.5%)
• 0.8 mm Thin Printed Circuit Board
• Auto Reset Support
• Equipped with 3.3 V Regulator
• Input voltage: 3.3 V~12 V
• Output current: 150 mA (max)
• Built-in overcurrent protection circuit
• Power and Status LEDs
• Analog pins: 8
• Digital I/O: 14
• Size: 18 x 33 mm
• [Reference]
• Pro Mini Graphical Datasheet
• Pro Mini Getting Started Tutorial
• USB to serial UART Boards Hookup Guide
• How to Install FTDI Drivers
• FTDI Drivers
• GitHub
