4-1775-01 Thin copper plate (With slit)
Product Description
Product Model: 4-1775-01Product Brand: REX Features Thi […]
Contact Us
Product Details
Product Model: 4-1775-01
Product Brand: REX
Features
- Thin nickel or copper plates are finely grooved in microns by electrocasting.
- Unlike conventional laser drilling, the edges of the grooves are sharp and smooth, and the parallelism of the grooves is very high.
Spec
- Slit Width W (μm) x Length (mm): 5 ± 2 x 3
- Slit Width Tolerance (μm): ± 2.0
- material: 99.9% pure nickel
- Diameter of substrate: Φ 9.5 + 0.0/-0.1 mm
- Edge Depth (a): 3 μm
- Position Tolerance for Slit: ± 0.2 mm
- Substrate thickness (t): 20 ± 5 μm
- *Also available with mount (aluminum frame). Please contact us.
