63-4800-61 ［Discontinued］Surface Mount (SMT) Board SSOP Epoxy Glass Double-Sided 81.6 x 61.34 x 1.5mm FR4 RE931
Product Description
Product Model: 63-4800-61Product Brand: Roth Elektronik […]
Contact Us
Product Details
Product Model: 63-4800-61
Product Brand: Roth Elektronik
Features
- SSOP Adaptor Boards, RE931. RE931 is offered as a board of 7 individual components parts (RE931-01, RES931-02, RE931-03, RE931-04, RE931-05, RE931-06, RE931-07). It features a pre-scratched rated break point for the separation of individual modules from the board. Adaptor board, suitable for 7 different SSOP Size: 61.40x81.70mm Pad spacing: 0.65mm / 0.635mm FR4 epoxy fibreglass laminate Material thickness: 1.5mm Double-sided, 35μm copper Through-holes Ø 1.00mm Soldered and component sides coated with chemical gold and solder mask
Spec
- Quantity：1piece
- SMD Component Type : SSOP
- Base Material : Epoxy Glass Fabric Laminate
- Number of Sides : 2
- Dimensions : 81.6 x 61.34 x 1.5mm
- Copper Thickness : 35µm
- Hole Diameter : 1mm
- Hole Pitch : 2.54mm
- FR Material Grade : FR4
- Length : 81.6mm
- Thickness : 1.5mm
- Width : 61.34mm
- CODE No.:463-2831
