63-4602-48 TE Connectivity DPDT Toggle Switch, Latching, Panel Mount 317-651
Product Description
Product Model: 63-4602-48Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-4602-48
Product Brand: RS PRO
Features
- The '(on)' of the CSA
- bias switch indicates the momentary 'on' position.
- Toggle Switch, Miniature, Long Flat Lever
- Switch with Long Flat Lever in Chrome Finish for Fashion and Easy Operation Gold Contact: Part No.: < 317-617') 317-617/, < 317-639') 317-639/, < 317-623') 317-623/Silver Contact: Part No.: < 317-645') 317-645/, < 317-651') 317-651/, < 317-673') 317-673/Reduced Operation Force Glass Fiber Polyester Case
Spec
- Contact Configuration:DPDT
- Switch Operation:Latching
- Contact Current Rating:6 A @ 250 V ac
- Mounting Type:Panel Mount
- Terminal Type:Solder
- Panel Cut Out Diameter:6.2mm
- Actuator Length:11.5mm
- Actuator Material:Chrome Plated Brass
- Contact Resistance:10mΩ
- Contact Material:Fine Silver
- CODE No.:FTN7904
