automaticdiluter
65-2060-50 Fluororesin (PTFE) Quick Connector Plug QCL-WV-2P (Rc1/4) NR1016-001
Product Description
Product Model: 65-2060-50Product Brand: Flon Chemical F […]
Contact Us
Product Details
Product Model: 65-2060-50
Product Brand: Flon Chemical
Features
- Since the connection part is made of fluororesin with excellent corrosion resistance, it can be ***d in all kinds of liquids such as strong acids, strong alkalis, and organic solvents and has high stability.
- Beca*** the Teflon spring has a metal spring embedded in Teflon, it has excellent performance in terms of temperature and leakage performance.
- The wetted part has excellent corrosion resistance beca*** it is all made of fluorine resin.
- The auto stop valve is a strong and stable Teflon spring, so there is fluid leakage.
- Can be attached and detached with one touch beca*** of the ball lock system.
- For all fluid piping and connections.
Spec
- Thread Size: Rc1/4
- Operating temperature range: 5~70°C
- Applicable fluids: acid, alkali, ultrapure water
- Maximum working pressure: 0.45 MPa
- Material/Finish: Body/Fluororesin, O-Ring/Fluororubber
- Country of Origin: Japan
- Securities Code: 201-8987
