1-8346-21 AIR driven diaphragm pump N5100020A
Product Description
Product Model: 1-8346-21Product Brand: JABSCO Features […]
Contact Us
Product Details
Product Model: 1-8346-21
Product Brand: JABSCO
Features
- It is an ultra-compact air-driven pump.
- The hose socket is detachable for easy hose piping.
- There is no pressure drop at various capacities from zero to maximum flow.
- It can be installed on top of the tank beca*** it is dry-operated and fully self-priming.
Spec
- maximum flow rate (L/min) : 9.5
- Maximum Discharge Pressure (kg/cm2): 5.5
- material: Wetted Part/POM (polyacetal), Diaphragm/Valve/Viton (R)
- Size: 157 x 105 x 61 mm
- Maximum air pressure: 5.5 kg/cm2
- Port Port Port: 3/8 "
- Air Port: 1/4 "
- Weight cookies: 500 g
- Maximum self-priming force: 8.5 m
- Operating Temperature: Maximum 49 ° C
- Viscosity ***d: 250 cP max.
- Applications: Can be ***d for food and beverage equipment, washing machines, chemical equipment, and industrial equipment.
