Spec

• [Max Save capacity]
• *Canister Count: 6
• *Number of 540 mL straws when using C -10 cane: 0.5
• *Number of 0.5 mL straws (1 stage, Bulk): 780
• *Number of 150 mL or 2.0 mL ampules when using a 5 cane cane cane cane: 1.2
• [performance]
• *Liquid nitrogen capacity (L): 20.5
• *Static evaporation rate (L)/day * 1: 0.095 (* 1 Static evaporation rate and number of days to store still are normal nominal values. The actual evaporation rate and the number of days of storage vary dep***ing on the *** of the container and the location of the container. )
• *Refill period (full filling) * 2: 135 (* 2 Refill period is a reference value to estimate the performance of the container under normal operating conditions. The actual period varies dep***ing on installation conditions and usage conditions. )
• [Container Dimensions]
• *Neck Diameter (mm): 55
• *overall height (mm): 660
• *outer diameter (mm): 368
• *Canister High (mm): 279
• *Canister diameter (mm): 41.9
• *Empty weight (kg): 11.8
• *Filled Weight (kg): 28.3
