Spec

• Measuring range (%): 0.04 ~ 5.00
• Type: For safety management
• Number of pieces: 1
• Detection principle: NDIR method
• Detection method: Diffusion method
• Alarm setting values: OFF (AL1)/0.50% (AL2)
• Response time: 40 seconds or less (T 90)
• Alarm operation: 2-step alarm, LED lamp flashing, electronic buzzer
• External output: Relay non-voltage 1 c contact, DC 30 V/1 A
• Analog output: 4 -20 mA
• Size: 167 x 40 x 82 mm
• Power supply: 100 VAC (AC adapter included)
• Operating temperature range: 0 ~ 40 degrees Celsius
• Operating humidity: 15 ~ 85% RH (noncondensing)
• Weight: 250 g
