4-2579-01 Flow rate Micrometer 8 to 350 uL/min NTFD-1.6S-0.35
Product Description
Product Model: 4-2579-01Product Brand: Surpass Industry […]
Contact Us
Product Details
Product Model: 4-2579-01
Product Brand: Surpass Industry
Features
- A minute flow meter that can measure from a minimum of 8 uL/min to a maximum of 35 mL/min.
- The TOF measurement method ***s a thermal marker, and high-precision measurement is achieved by our unique digital processing.
- If the optional communication adapter is ***d together, various functions such as power supply to the main unit and flow monitoring can be performed.
- The integrated display structure allows the flow rate to be visually confirmed in the field, making it suitable for experimental and research applications.
Spec
- flow rate range: 8 to 350 uL/min
- Connection Shape/Tube: outer diameter Φ 1.6 mm/1/16 "Hard Tube
- Fluid ***d: pure water, Liquid medicine (Fluid which does not corrode the wetted part and fluid which does not solidify adhering to the wetted part)
- pressure of *** range : 0 to 500 kPa
- Voltage: 700 kPa
- Accuracy: Maximum Measurement flow rate < 20% ± 1% F.S. 20% or More ± 5% R.D. (To pure water.)
- Fluid Temperature/Environmental Temperature Range: 15 to 50 ° C
- materials of liquid contact part: PTFE/Quartz Glass
- Output Specifications: flow rate (electric current)/4 to 20 mA, flow rate (frequency pulse)/NPN Open Connector
- power supply Voltage : DC24V ± 10%
- Power Consumption: MAX 50 mA
