64-1726-87 Applied Motion Systems Dual Hybridge Stepper Motor 1.8°, 0.88Nm, 12 → 70 V dc, 5 A, 8 Wires STM23IP-2EE
model:
64-1726-87
brand:
Applied Motion Systems
Product Description
Product Model: 64-1726-87Product Brand: Applied Motion […]
Contact Us
Product Details
Product Model: 64-1726-87
Product Brand: Applied Motion Systems
Features
- Integrated Steppers STM23IP. The STM23IP is an integrated Drive and Motor, fusing step motor and drive technologies into a single device, offering savings on space, wiring and cost over conventional motor and drive solutions. Drive + Motor + Control in one unit 4 quadrant controller Dynamic Current Control Anti-Resonance Torque Ripple Smoothing Microstep Emulation Stall Prevention/Detection NEMA 23 frame size Input voltage 12-70 Vdc 3 digital input, 1 analog input 1 digital output Ethernet and Ethernet/IP interface Encoder. Operation Mode: Step and direction CW/CCW pulse A/B quadrature pulse velocity (oscillator, joystick) streaming commands (SCL) SiNet Hub compatible Executes stored Q programmes
Spec
- Quantity:1piece
- Step Angle:1.8°
- Holding Torque:0.88Nm
- Number Of Wires:8
- Voltage Rating:12 → 70 V dc
- Frame Size:23mm
- Stepper Motor Type:Dual Hybridge
- Shaft Diameter:6.35mm
- Current Rating:5 A
- Shaft Length:18.4mm
- Depth:92.4mm
- Standards Met:CE EN61800-3:2004, RoHS Compliant
- CODE No.:877-7247
