64-1718-92 10 Way Through Hole Piano Dip Switch SPST, Piano Actuator DPL10V
Product Description
Product Model: 64-1718-92Product Brand: APEM Features D […]
Contact Us
Product Details
Product Model: 64-1718-92
Product Brand: APEM
Features
- DP/DPL Series Piano DIP Switches. A range of PCB SPST DIP switches. DP series have short keys and DPL are the long key type. Upto 10 way Operation force 400gf max 2mm Stroke 25mA 24Vdc, switching rating 100mA 50Vdc, non switching rating
Spec
- Quantity:1set(17pieces)
- Contact Configuration:SPST
- Contact Current Rating:25 mA
- Contact Material:Phosphor Bronze
- Number of Positions:10
- Mounting Type:Through Hole
- Actuator Type:Piano
- Package Style:DIP
- Maximum Operating Temperature:+70°C
- Minimum Operating Temperature:-20°C
- Operating Temperature Range:-20 → +70°C
- Voltage Rating:24V dc
- CODE No.:877-2356
