Spec

• Temperature point: 37 deg. C1 point, speed
• External Dimensions (mm): 690 x 400 x Water Tank 195, Power Distribution Board 145
• Internal Dimensions (mm): 480 x 350 x 150
• Effective Dimensions: 380 x 350 x 150 mm
• Shaking rate: 12~110 strokes per minute (50 Hz)
• Amplitude: 20~40 mm (3 Step Variable Type)
• Shaking motor: Electronically controlled motor (25 W)
• Shaking Rack Size: 320 x 300 x 60 mm (Stainless Steel Spring Rack), Maximum Number of Racks: 240
• Temperature setting range: room temperature +10~60°C
• Temperature accuracy: ±0.1°C
• Temperature Control Method: Digital Temperature Indication Dial Setting Type (P Control Method)
• Heater (Capacity): Sheathed Wire Type 1 kW
• Stirrer: Jet Stirring Method
• Material: Interior/Rack/Stainless Steel (SUS304), Exterior/Steel Plate Baked Paint
• Safety devices: Heat-sensitive heater dry fire prevention device (manual reset type), power f***
• Power: 100 VAC 50/60Hz 11 A
• Weight: Approx. 21 kg
• On-site validation services (IQ/OQ) are also available.
• Please contact us.
• *On-site validation service is a service where installation qualification (IQ) and operational performance qualification (OQ) are performed and inspection documents are submitted at the installation site.
• *If you would like IQOQ on site, please contact us separately. The installation address is required for the quotation.
