3-9086-01 Spectrum Analyzer 9kHz - 3.25 GHz GSP-9330VGT
Product Description
Product Model: 3-9086-01Product Brand: TEXIO TECHNOLOGY […]
Contact Us
Product Details
Product Model: 3-9086-01
Product Brand: TEXIO TECHNOLOGY
Features
- It is compact, lightweight and can be powered by a battery.
- A 3.25 GHz high-speed spectrum analyzer that supports sweep speeds of up to 286 μs (FAST).
- Parameters including AM modulation degree, frequency shift, modulation rate, carrier power, carrier frequency offset, and SINAD can be measured.
- The frequency counter function enables accurate frequency measurement up to 1 Hz resolution.
Spec
- Frequency range: 9 kHz to 3.25 GHz
- Frequency Resolution: 1Hz
- Frequency reference accuracy: ±(Period from final adjustment x aging rate) + stability over the entire temperature range + supply voltage stability
- Marker frequency counter Resolution: 10Hz, 100Hz, 1000Hz
- Marker frequency counter accuracy: ±(Marker Frequency Display x Frequency Reference Accuracy + Counter resolution)
- Frequency span range: 0Hz (zero span), 100Hz to 3 GHz
- Frequency Span Resolution: 1Hz
- Frequency span accuracy: ±frequency resolution, RBW: Auto
- With tracking generator and GP-IB
- Size: 350 x 100 x 200mm
- Weight : about 4.5kg (full option time)
- Power supply : AC100 to 240 V 50/60Hz
- Power Consumption: about 82 W
- Accessories: power cord (For AC100V)
