Spec

• External Dimensions (mm): 415 x 503 x 441
• Furnace Internal Dimensions (mm): 160 x 240 x 130
• Capacity (L): 5.0
• Operating Temperature Range: 100~1150°C (0.5°C Unit)
• Temperature distribution accuracy: ±3°C at 1000°C
• Temperature rise time: about 28 minutes Room temperature →1150°C
• Control Method: Program Operation (50 patterns, 100 segments)
• Temperature sensor: K thermocouple
• Heater capacity: 1.8 kW
• Furnace: Ceramic Fiber
• Safety devices: overcurrent breaker, overtemperature setting device, door opening/closing sensor, key lock function, exterior temperature-sensitive cooling fan, microcomputer abnormality detection device (Heater Disconnection, Thermocouple Disconnection, Memory Content Abnormality, Overtemperature Abnormality, Control Board Abnormality)
• External output: recorder thermocouple output, gas automatic introduction output 1~2, event contact output 1~4, deodorizer output, in-operation/***/alarm contact output, 3 color lighting output, SD card slot
• Exhaust Diameter: φ23.5 mm
• Weight: 33 kg
• Power Supply (50/60Hz): 200 VAC Single Phase
• Current Capacity *: 9 A (* All numerical values are representative values and are not guaranteed. *AC Cord 3 m/5.5SQ/With Ground (With M5 Screw Compatible Crimp Terminal) * Ensure that the current capacity of the power supply is sufficient. )
• Accessories: Hearth plate, exhaust plug, exhaust sleep, AC cord
• Options (Sold Separately): Deodorizer (ES71, ES72), Smoke Exhaust Device (VF71, VF72), Gas Introduction Unit (KDG-300, -1500, -3000, -5000), 3-Color Lighting, Separate System Excess Temperature Rise Sensor, Body Fixing Bracket Unit, Ground Fault Breaker, Platinum Thermocouple, Dedicated Wagon (KDW-100, KDW-200), Temperature Sensor for Recorder Output
• *There is also a vacuum gas replacement furnace type. Please contact us.
• Model Number: 500Plus
• This product can be inspected and inspected. Please contact us.
• *Inspection and inspection service is a service that inspects the control (inside temperature, etc.) and electric engine at the time of shipment or at the customer's site, and issues an inspection certificate.
• *Transportation, loading, installation and assembly costs are required separately. Please contact us.
