Features

• UL60950 p***ing, ANSI/AAMI ES60601-1, 2 MOOPs p***ing. Murata Isolated 3W Triple Output DC/DC Converter - MGJ3 Series. The Murata Power Solutions MGJ3 series is a range of DC-DC converters with high isolation and dv/dt requirements commonly seen in bridge circuits ***d in motor drives and inverters. These DC-DC converters offer a choice of asymmetric output voltages allowing optimum drive levels for best system efficiency and EMI. The MGJ3 isolated DC-DC converters have 3 configurable outputs and they are ideal for powering ‘high side ‘ and ‘low side ‘ gate drive circuits for IGBTs, Silicon Carbide and Mosfets in bridge circuits. No opto feedback Patents P***ing Optimised bipolar output voltages for IGBT/SiC ; Mosfet gate drives 3 outputs configurable for all gate drive applications: +15V/-5V, +15V/-10V ; +20V/-5V outputs Characterised dv/dt immunity 80kV/μS at1.5kV Characterised partial discharge performance 5.2kVDC isolation test voltage ‘Hi Pot Test ‘ Ultra low coupling capacitance 15pF SMD package 5V, 12V ; 24V input voltages 105°C operating temperature
