65-0851-04 Toyo Spring Hose for Factory Equipment Piping and Various Mechanical Piping TS-32-1
Product Description
Product Model: 65-0851-04Product Brand: TOYOX CO., LTD. […]
Contact Us
Product Details
Product Model: 65-0851-04
Product Brand: TOYOX CO., LTD.
Features
- "Main Application": For suction and pressure feeding of plant piping and mechanical piping. "Multi-Purpose Resin Hose": Pressure resistant hose that can be ***d for pressure feeding and suction (vacuum) of various fluids such as water, oil, chemicals, and air. "Prevention of breakage and collapse": Reinforced structure with hard steel wire coils, resistant to breakage and collapse, and can stably supply fluid. "Long-Lasting": The inner and outer surfaces of the hose are excellent in oil resistance, hard and long life. "Plenty of sizes": Pressure resistant hose for suction and pressure feeding with a wide variety of sizes (inner diameter 6~100 mm). "Transparency": Highly transparent and can confirm the fluid inside. "Compliance with RoHS2 (as of October 2021).
Spec
- Inner diameter x Outer diameter (mm): 32 x 41
- Pressure (Mpa): -0.1 to 0.3
- Operating temperature range: -5 to 60 °C
- Length: 1 m
- Material: Body/Soft vinyl chloride, Reinforcement/Hard Steel Wire
- Minimum b***ing radius: 130 mm
