64-1384-12 Nexperia 74LVC1G00GV,125 2-Input NAND Logic Gate, 5-Pin SC-74A 74LVC1G00GV,125
Product Description
Product Model: 64-1384-12Product Brand: Nexperia Featur […]
Contact Us
Product Details
Product Model: 64-1384-12
Product Brand: Nexperia
Features
- 74LVC Family Logic Gates. Low-Voltage CMOS logic Single gate package Operating Voltage: 1.65 to 5.5 V Compatibility: Input LVTTL/TTL, Output LVCMOS
Spec
- Quantity:1set(3000pieces)
- Logic Function:NAND
- Mounting Type:Surface Mount
- Number of Elements:1
- Number of Inputs per Gate:2
- Schmitt Trigger Input:No
- Package Type:SC-74A
- Pin Count:5
- Logic Family:LVC
- Input Type:TTL
- Maximum Operating Supply Voltage:5.5 V
- Maximum High Level Output Current:-32mA
- Maximum Propagation Delay Time @ Maximum CL:7.5 ns @ 50 pF
- Minimum Operating Supply Voltage:1.65 V
- Maximum Low Level Output Current:32mA
- Length:3.1mm
- CODE No.:165-8586
