64-1376-77 TRACOPOWER TMV HI 1W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 5.5 V dc, Voltage out 9V dc TMV 0509SHI
Product Description
Product Model: 64-1376-77Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 64-1376-77
Product Brand: TRACOPOWER
Features
- UL/cUL 60950-1 2nd edition, IEC 60950-1:2005 (2nd edition); Am 1:2009 EN 60950-1:2006/A11:2009/A1:2010/A12:2011. UL/cUL 60950-1 IEC/EN 60950-1. 3. Traco 1W SIP Unregulated Isolated DC-DC Converter - TMV-HI Serie. The Traco TMV-HI Series is a family of 1W non-regulated DC/DC converters with very high I/O isolation of 5200Vdc. These non-regulated DC/DC converters come in a very compact SIP-7 package. The TMV-HI series of DC-DC- converters is ideal for IGBT applications. Ultra compact SIP-7 package Very high I/O-isolation 5200 VDC Dedicated for IGBT applications Operating temperature range -40°C to +85°C Industry standard pinout
Spec
- Quantity:1set(10pieces)
- Output Voltage:9V dc
- Input Voltage Range:4.5 → 5.5 V dc
- Isolation Voltage:5.2kV dc
- Power Rating:1W
- Output Current:111mA
- Mounting Type:Through Hole
- Number of Outputs:1
- Efficiency:75%
- Package:SIP 7
- Minimum Temperature:-40°C
- Maximum Temperature:+85°C
- Series:TMV HI
- CODE No.:166-6139
