Electronic/Electrical Parts and Controll Equipments
64-1359-24 Bourns SRN6028 Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 μH ±30% Wire-Wound 3.7A Idc SRN6028-2R2Y
Product Description
Product Model: 64-1359-24Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 64-1359-24
Product Brand: Bourns
Features
- SRN6028 Series Semi-Magnetically Shielded Power Inductors. Bourns SRN6028 Series comes in various sizes and have a semi-shielded construction. Features and Benefits: Inductance range: 0.90 μH to 100 μH Rated current up to 4.6 A RoHS compliant and halogen free Applications in DC-DC converters, Notebook computers, Digital video cameras, HDDs, Cell phones, Televisions and LCD display
Spec
- Quantity:1bag(10pieces)
- Inductance:2.2 μH
- Maximum DC Current:3.7A
- Length:6mm
- Depth:6mm
- Height:2.8mm
- Dimensions:6 x 6 x 2.8mm
- Shielded:Yes
- Tolerance:±30%
- Maximum DC Resistance:26mΩ
- Series:SRN6028
- Core Material:Ferrite
- Minimum Operating Temperature:-40°C
- CODE No.:813-5716
