Features

• UL; CSA. For white body versions see stock number ; 737-3787 737-3787 typically. For panel sealing *** gasket stock number ; 737-3863 737-3863. Otto P9 - Black Body Push Button Switch IP68. Momentary action P9 series push button switches feature a contoured dome style push button in either a low button profile or a high button profile with a threaded case for hex nut mounting and a short behind panel depth of approximately 12mm. At a full rated load of 5 amps resistive or 3 amps inductive the P9 life is approximately one million mechanical operations with an electrical life of 25,000 operations. The P9 series has a low contact resistance for low level switching capability as well as being a precision designed switch for *** in panels, control grips, computers, instruments, heavy equipment and other demanding applications where attractive rugged push button switches are required. Sealed to IP68 Watertight (submersible to 1 meter water pressure) 1 N/O + 1 N/C momentary contacts (form Z) Flush and raised dome button styles available in a wide choice of colours. Matt or standard finish available Threaded body (panel knock out 12.827mm) Small size with black bezel and body Supplied with nut ; panel seal gasket Operating Temperature: -55 to +85°C Contact Rating: 5A @ 28Vdc or 115Vac; 2.5A @ 250Vac
