64-1286-35 Wurth WE-TPC Series Type 2811 Shielded Wire-wound SMD Inductor with a Ferrite Core, 4.7 μH ±30% Wire-Wound 900mA Idc 744028004
model:
64-1286-35
brand:
Wurth Elektronik
Product Description
Product Model: 64-1286-35Product Brand: Wurth Elektroni […]
Contact Us
Product Details
Product Model: 64-1286-35
Product Brand: Wurth Elektronik
Features
- WE-TPC Series 2.8mm Square Magnetically Shielded Wire Wound Chokes. WE-TPC Series is extremely flat power inductor with high current capability Magnetically shielded which results in a low leakage field Operating temperature: –40 to +125°C Applications: Portable power (e.g. PDA, digital camera, PCMCIA cards and displays); DC/DC converter; Embedded PC; Mobile data gathering, telemetric
Spec
- Quantity:1set(1500pieces)
- Inductance:4.7 μH
- Maximum DC Current:900mA
- Package/Case:2811
- Length:2.8mm
- Depth:2.8mm
- Height:1.1mm
- Dimensions:2.8 x 2.8 x 1.1mm
- Shielded:Yes
- Tolerance:±30%
- Maximum DC Resistance:310mΩ
- Series:WE-TPC
- Core Material:Ferrite
- Maximum Self Resonant Frequency:70MHz
- Minimum Operating Temperature:-40°C
- CODE No.:163-3571
