3-6696-01-20 Function Generator 1μHz - 10MHz With Calibration Certificate AWG1005
model:
3-6696-01-20
category:
toner
Product Description
Product Model: 3-6696-01-20 Features Displays related s […]
Contact Us
Product Details
Product Model: 3-6696-01-20
Features
- Displays related settings and parameters in text and graphic format on a 3.95 inch TFT LCD display.
- It supports 5 basic waveforms and 48 arbitrary waveforms.
- 26 arbitrary waveforms can be stored in nonvolatile memory.
Spec
- Model number: AWG 1005
- Frequency range (MHz): 1 μHz to 10 MHz
- Resolution (μHz): 1
- Analog channels: 2
- Output waveform: sine wave, square wave, pulse wave, ramp wave, noise, ARB (arbitrary wave)
- Sample rate: 125mS/s
- Record length: 8k points
- Vertical Axis Resolution: 14 bits
- Amplitude (50 ohm load): 1 mV to 10 Vp-p
- Amplitude Resolution: 1 mVp-p/14 bits
- Frequency: Sine wave/1 μHz -25 MHz, Square wave/Pulse wave/1 μHz to 5 MHz, Lamp wave/1 μHz to 1 MHz, Noise/25MHz (-3 dB), ARB (arbitrary wave)/1 μHz to 10 MHz
- Interface: USB
- Size: 235 x 110 x 295mm
- Weight: 3kg
- Power supply : AC100V 50/60Hz
