Features

• Souriau Trim Trio Crimp Contact Tooling Dies and Crimp Tool Handle. The Souriau Shandles Crimping Tool + Crimping Heads are equipment designed with a professional *** in mind. Manufactured from high-quality materials that guarantee durability and long life operation. The Shandles Crimp Tool ( ; 787-9588 787-9588 ) is a crimp tool without a die and can be ***d with Souriau Trim Trio contacts, including MSM-MSG -MB rectangular connectors, SMS Qikmate connectors, UTO - UTS - UTL - UTG and UTP - MBG circular connectors. TRIM TRIO dies compatible with a crimp tool handles are: Souriau UTS Series, Crimping Head, Wire size 16 -14 AWG, Hex size 1.6mm ( ; 787-9557 787-9557 ) Souriau UTS Series, Crimping Head, Wire size 16 -14 AWG, Hex size 1.6mm ( ; 787-9563 787-9563 ) Souriau UTS Series, Crimping Head, #16 RM RC Contact ( ; 787-9566 787-9566 ) Souriau UTS Series, Crimping Head, Wire size 26 - 20 AWG, Hex size 1.6mm ( ; 787-9569 787-9569 ) Souriau UTS Series, Crimping Head, Wire size 18 -16 AWG, Hex size 1.6mm ( ; 787-9572 787-9572 ) Souriau UTS Series, Crimping Head, Wire size 26 -18 AWG, Hex size 1.6mm ( ; 787-9575 787-9575 ) Souriau UTS Series, Crimping Head, Wire size 26 - 20 AWG, Hex size 1.6mm ( ; 787-9759 787-9759 ) Souriau Crimping Head, Wire size 30 - 20 AWG ( ; 851-0075 851-0075 ) Souriau Crimping Head, Wire size 16 - 14 AWG ( ; 851-0079 851-0079 ) Features and Benefits: Made from highly durable materials The guaranteed ***urance of 5000 cycles Typical Applications: Maintenance ; repair Electrical Installations Cable assemblies FAQ ‘s: What is the difference between un-insulated and insulated crimp tools? Un-insulated crimp tools are typically ***d for general applications, whereas the insulated crimp tools have been VDE tested up to 1000 V, designed for *** where electrical current is present. How do you maintain the product? Axles and other movable parts should be regularly lubricated. Lubrication* is recomm***ed at least every 10,000 cycles whenever the tool is exposed to contaminants. Adjustment of the crimping die nests should also be checked. Readjustment of the pressure adjustment axle is necessary when the pre-load of the tool decreases significantly. The Importance of a High-Quality Crimp When a crimping tool is ***d on a terminal, two crimps take place at the same time. One is the electrical connection between the conductor and terminal. The other is the insulation crimp which provides strain relief against vibration and tension. It is important that the electrical connection is gas-tight without any voids between the wire strands and the terminal. If there any voids present, then corrosion can occur causing resistance and excessive heat which damages the electrical connection. Using a good quality crimping tool will ensure that a full, gas-tight crimp is produced preventing future deterioration of the electrical connection and insulation breakage.
