Electronic/Electrical Parts and Controll Equipments
64-0669-70 White Tactile Switch, Single Pole Single Throw (SPST) 50 mA @ 12 V dc 1.3mm Through Hole 431256038726
model:
64-0669-70
brand:
Wurth Elektronik
Product Description
Product Model: 64-0669-70Product Brand: Wurth Elektroni […]
Contact Us
Product Details
Product Model: 64-0669-70
Product Brand: Wurth Elektronik
Features
- Tactile Switch Right Angle Terminal. Steel cover Silver cladded Stainless Steel contacts Wave soldering 260°C 10sec. Max Operating temperature range -40°C to +85°C
Spec
- Quantity:1piece
- Contact Configuration:Single Pole Single Throw (SPST)
- Terminal Type:Solder
- Switch Operation:Momentary
- Actuator Length:1.3mm
- Actuator Colour:White
- Actuator Type:Tactile
- Length:7mm
- Width:6.85mm
- Dimensions:6.85 x 7mm
- Mounting Type:Through Hole
- Contact Current Rating:50 mA @ 12 V dc
- Operating Force:260 g
- Mechanical Life:200000Cycles
- CODE No.:785-6392
