64-0623-16 EPCOS B82476A1 Series Type SMD Wire-wound SMD Inductor with a Ferrite Core, 22 μH ±20% Wire-Wound 2.7A Idc B82476A1223M000
Electronic/Electrical Parts and Controll Equipments

64-0623-16 EPCOS B82476A1 Series Type SMD Wire-wound SMD Inductor with a Ferrite Core, 22 μH ±20% Wire-Wound 2.7A Idc B82476A1223M000

model: 64-0623-16
brand: EPCOS

Product Description

Product Model: 64-0623-16Product Brand: EPCOS Features […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 64-0623-16
Product Brand: EPCOS

Features

  • B82476A1 Series Wire Wound Chokes. B82476A1 Series SMD power inductors with a ferrite core and enamel copper wire windings. The high current rated B82476A1 series have a low DC resistance and are Suitable for lead-free reflow soldering as referenced in JEDEC J-STD 020D. Applications for the B82476A1 Series include: Filtering of supply voltages; Coupling, decoupling; DC/DC converters; Automotive electronics; Industrial electronics; Consumer electronics. Rated inductance - 10μH to 470μH Rated current - 3.90A to 0.5A Temperature range up to +150°C

Spec

  • Quantity:1set(750pieces)
  • Inductance:22 μH
  • Maximum DC Current:2.7A
  • Package/Case:SMD
  • Length:12.95mm
  • Depth:9.4mm
  • Height:5.08mm
  • Dimensions:12.95 x 9.4 x 5.08mm
  • Tolerance:±20%
  • Maximum DC Resistance:50mΩ
  • Series:B82476A1
  • Core Material:Ferrite
  • Inductor Construction:Wire-Wound
  • CODE No.:162-0209
