64-0622-26 Bourns SRN3010 Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 1.2 μH ±30% Wire-Wound 2.1A rms Idc SRN3010-1R2Y
Product Description
Product Model: 64-0622-26Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 64-0622-26
Product Brand: Bourns
Features
- SRN3010 Series Semi Magnetically Shielded Wire Wound Chokes. SRN3010 Series Miniature SMD Semi-shielded Power Inductors. Component height of 1.0mm Inductance range from 1 to 47μH Rated current of up to 2.3A. Applications include: DC/DC converters; Notebook computers; Digital video cameras; HDDs; Cell phones; Televisions, LCD displays
Spec
- Quantity:1set(2000pieces)
- Inductance:1.2 μH
- Maximum DC Current:2.1A rms
- Length:3mm
- Depth:3mm
- Height:1mm
- Dimensions:3 x 3 x 1mm
- Shielded:Yes
- Tolerance:±30%
- Maximum DC Resistance:81mΩ
- Series:SRN3010
- Core Material:Ferrite
- Minimum Operating Temperature:-40°C
- CODE No.:172-9561
